Heavy-Duty Cable Carriers · 80 Series
80 Series Bridge-type cable carrier, inner height 80 mm, inner width 100 mm
WSL37-80-100 is a CNWSL Heavy-Duty Cable Carriers 80 Series carrier with 80 mm inner height, 100 mm inner width, PA6+GF30 reinforced nylon, and bend radii R150 / R200 / R250 / R300.
Specifications
- Model code
- WSL37-80-100
- Inner height (H)
- 80 mm
- Inner width (B)
- 100 mm
- Opening type
- Bridge-type
- Material
- PA6+GF30 reinforced nylon
- Connector
- WSL37-80-100C
Available bend radii
The same size can be ordered with different bend radii (R). Length and travel can be customized to your duty cycle.
| Bend radius | Code example | Notes |
|---|---|---|
| R150 | WSL37-80-100-R150 | Long travel / thick cables |
| R200 | WSL37-80-100-R200 | Long travel / thick cables |
| R250 | WSL37-80-100-R250 | Long travel / thick cables |
| R300 | WSL37-80-100-R300 | Long travel / thick cables |
Features
- Bridge-type design for industrial cable protection
- Inner height 80 mm / inner width 100 mm
- Bend radii R150, R200, R250, R300
- Material PA6+GF30 reinforced nylon
- Matching connector WSL37-80-100C
Request a quote
Tell us your machine type, travel and bend-radius needs—we will reply with pricing promptly.
